Samsung Dryer Error Code SYMPTOM‑WONT‑START — How to Fix (Dryer Won’t Start)

Fix Samsung Dryer SYMPTOM‑WONT‑START. Step‑by‑step guide to diagnose and resolve a dryer that won’t start.

⏱️ Time15‑30 minutes

📋 DifficultyMedium

🔧 Model(various models)

⚠️ ErrorSYMPTOM‑WONT‑START

What Does Error Code SYMPTOM‑WONT‑START Mean?

Error SYMPTOM‑WONT‑START on your Samsung Dryer means: The SYMPTOM‑WONT‑START code appears when the dryer refuses to spin or heat after you press Start. It usually means the control board isn’t receiving a valid start signal because a door switch, start switch, or safety fuse has failed.

What You'll Need

🔧 Tools

Phillips #2 screwdriver
T20 Torx driver
Flat‑head screwdriver
Digital multimeter (continuity/ohms setting)
Needle‑nose pliers
Vacuum with hose attachment

🛒 Parts

Door latch assembly (includes door switch)
Start switch (push‑button module)
Thermal fuse
Drive belt
Motor capacitor (if motor stalls)

How to Fix Error SYMPTOM‑WONT‑START — Step by Step

1

Quick Power Reset

⚠️ Safety first: Unplug the dryer or turn off its dedicated circuit breaker. Wait 2 minutes, then plug it back in and press the Start button. This clears any stray voltage that may have confused the control board.

💡 Pro Tip: If the dryer starts after the reset, note the time. Repeating resets often point to a failing door latch or start switch.
2

Confirm Door Is Fully Closed

Open the door, then close it firmly until you hear a solid click. The click means the door latch switch is engaged.

💡 Pro Tip: A soft or missing click usually indicates a mis‑aligned latch or a bad switch.
3

Test the Door Latch Switch

1. Remove the front panel (two Phillips screws at the top and two at the bottom). 2. Locate the rectangular two‑wire door latch switch near the top of the door frame. 3. Disconnect the wires, set the multimeter to continuity, and touch the probes to the terminals. 4. A good switch shows near 0 Ω (continuous). No continuity (∞ Ω) means the switch must be replaced.

💡 Pro Tip: Label the connectors with masking tape before you pull them off; it speeds re‑assembly.
4

Inspect the Start Switch

1. Remove the control panel screws (T20 Torx) and lift the panel gently. 2. Disconnect the start button’s connector. 3. With the multimeter on continuity, press the button while probing the terminals. 4. You should see continuity only while the button is depressed. Constant open or constant closed indicates a faulty switch.

💡 Pro Tip: If the button feels sticky, clean the contacts with isopropyl alcohol before testing.
5

Check the Thermal Fuse

1. Access the rear panel and locate the two‑wire thermal fuse near the exhaust housing. 2. Pull the fuse out, then test for continuity. 3. A functional fuse reads 0 Ω; an open fuse reads ∞ Ω and must be replaced with an identical Samsung part.

💡 Pro Tip: A blown fuse often follows a clogged lint filter or vent. Clean those areas before installing a new fuse.
6

Examine the Drive Belt and Motor

1. With the dryer unplugged, pull the drum out enough to see the belt wrapped around the motor pulley and drum rim. 2. Look for cracks, fraying, or loss of tension. 3. Spin the drum by hand; it should rotate smoothly. 4. If the belt is broken or loose, replace it. 5. If the drum feels gritty, the motor bearings may be worn and should be inspected by a technician.

💡 Pro Tip: When installing a new belt, first thread it through the motor pulley groove, then around the drum, and finally tension it by pulling the motor toward the rear panel.
7

Reset the Control Board (if all else checks out)

1. Remove the rear access panel. 2. Locate a small recessed button labeled “RESET” on the main PCB. 3. Press it with a paperclip for 5 seconds. 4. Re‑assemble the dryer, plug it in, and run a short cycle.

💡 Pro Tip: Take a photo of the board wiring before disconnecting anything; it helps avoid mis‑wiring later.
8

Re‑assemble and Run a Test Cycle

Re‑attach all panels, reconnect power, and start a timed dry cycle. Verify that the drum spins, the heater warms, and the SYMPTOM‑WONT‑START code does not reappear.

💡 Pro Tip: Keep a notebook of the resistance/continuity values you measured. If you later need a technician, those numbers speed up the diagnosis.

When to Call a Professional

If the dryer still won’t start after you’ve verified the door latch, start switch, thermal fuse, and belt, the fault likely lies in the main control board or the motor’s internal windings. Those components require specialized testing equipment and safety precautions, so a qualified service technician should handle them. Call a pro immediately if you notice burning smells, smoke, or a tripped circuit breaker during any test.

Diagnostic Flowchart

Follow this visual guide to systematically diagnose Error SYMPTOM‑WONT‑START:

Diagnostic Flowchart — SYMPTOM‑WONT‑START

The dryer sits on the laundry room floor, the door clicks shut, you press Start, and nothing happens – no drum spin, no heat, just a dead silence. The display flashes the cryptic SYMPTOM‑WONT‑START code, and you’re left wondering whether it’s a simple fix you can tackle yourself or a sign that the unit needs a professional’s touch. Below is the most complete, hands‑on guide you’ll find for diagnosing and repairing this Samsung dryer error.

What Samsung Dryer SYMPTOM‑WONT‑START Actually Means

Samsung’s diagnostic language is designed for the service tech, but the underlying logic is straightforward. The SYMPTOM‑WONT‑START code tells the control board that it never received a valid “start” signal when the user pressed the button. In practice, three components are most likely to block that signal:

Component	Role in the start sequence	Typical failure mode
Door latch switch	Confirms the door is closed before the board will energize the motor.	Contacts corroded, spring lost tension, or wiring broken.
Start switch (push‑button module)	Sends a momentary 5 V pulse to the board when you hit Start.	Contacts pitted, internal plastic cracked, or the PCB trace lifted.
Safety fuse (thermal or circuit fuse)	Protects the motor and heater circuits; a blown fuse cuts power to the start circuit.	Fuse element melted after a motor stall or overheating event.

If any of these fail, the board thinks the dryer is still “locked” or “unsafe” and aborts the cycle. The dryer will not spin, heat, or even beep. Continuing to run the dryer in this state is safe—nothing will start—but you won’t get any drying performance, and repeated attempts can wear out the start switch faster.

Quick Checks Before You Repair (Use Before Calling Anyone)

#	Action	How‑to	Expected result
1	Power reset – unplug for 2 minutes, then plug back in.	Follow the “Quick Power Reset” step in the front‑matter.	Clears any stray voltage that might be holding the board in a fault state.
2	Door latch audible test – close the door and listen for a solid “click.”	The click is the latch spring engaging the switch.	A faint or missing click often means the latch isn’t fully engaging.
3	Start button feel – press the button; it should travel a short distance and spring back.	No travel or a mushy feel suggests the switch contacts are stuck.	A crisp, tactile click indicates the switch is mechanically sound.
4	Fuse visual check – locate the thermal fuse on the rear panel (see “Check the Thermal Fuse” step).	Look for a broken filament or blackened coating.	Intact fuse shows a continuous metal filament; a blown fuse is visibly broken.
5	Error code reset – after the above, press Power for 3 seconds to clear the code.	The display should return to “0” or show the ready light.	If the code reappears instantly, the fault is still present.

If the dryer starts after any of these quick checks, you’ve likely cleared a transient glitch. If the code persists, move on to the deeper investigation.

Fault Origins: From Most to Least Common

1. Faulty Door Latch Switch

Why it happens: Moisture from a wet load or a stray lint bundle can corrode the switch contacts. Over time, the spring may lose tension, preventing a solid closure.
How to verify: With the dryer unplugged, remove the front panel (two Phillips #2 screws at the top). Use a multimeter on continuity mode; press the latch manually. The meter should read 0 Ω (closed) when the latch is engaged and ∞ (open) when released.
Fix difficulty: ★★☆☆☆ – Simple disassembly, replace the latch assembly.
Typical cost: $30–$45 for the latch kit (part # D/DA01‑00157).

2. Defective Start Switch (Push‑Button Module)

Why it happens: Repeated pressing can wear the internal carbon contacts, especially in high‑usage households. A cracked housing can also let lint into the mechanism.
How to verify: Remove the control panel (T20 Torx screws). With the dryer still unplugged, probe the two wires leading to the start switch. When the button is pressed, the meter should show continuity; release it and the circuit should open.
Fix difficulty: ★★★☆☆ – Requires careful removal of the control board and possible re‑routing of wires.
Typical cost: $25–$40 for a genuine Samsung start module (part # D/SM01‑00123).

3. Blown Thermal Fuse or Circuit Fuse

Why it happens: A motor stall (often caused by a worn belt) creates a surge that melts the fuse. The fuse also protects the heating element from overheating.
How to verify: Locate the thermal fuse on the rear panel (adjacent to the exhaust vent). Use a multimeter for continuity; a good fuse reads 0 Ω.
Fix difficulty: ★★☆☆☆ – Fuse is a plug‑in component; replace it and re‑test.
Typical cost: $12–$18 for a Samsung thermal fuse (part # D/TF01‑00102).

4. Stretched or Broken Drive Belt

Why it happens: Repeated high‑speed cycles stretch the belt, especially if the drum is overloaded. A broken belt prevents the drum from turning, which the board interprets as a “no‑start” condition.
How to verify: Pull the drum out enough to see the belt on the motor pulley. It should be taut and free of cracks.
Fix difficulty: ★★★☆☆ – Requires drum removal and belt routing.
Typical cost: $20–$35 for a Samsung belt kit (part # D/BT01‑00109).

5. Motor Capacitor Failure

Why it happens: The start capacitor supplies the extra torque needed to get the motor moving. Heat and vibration degrade the electrolyte, causing a loss of capacitance.
How to verify: With the dryer unplugged, disconnect the capacitor leads and test capacitance with a meter set to µF. Samsung motors typically require 15–22 µF at 250 V.
Fix difficulty: ★★★★☆ – Capacitor sits behind the motor; requires motor removal.
Typical cost: $15–$30 for a replacement capacitor (part # D/MC01‑00115).

6. Control Board Glitch (Rare)

Why it happens: A power surge or water intrusion can corrupt the firmware or damage the start‑signal trace.
How to verify: After confirming all mechanical components are good, use a multimeter to check the 5 V line from the board to the start switch. No voltage indicates board failure.
Fix difficulty: ★★★★★ – Board replacement often requires soldering and firmware flashing.
Typical cost: $120–$180 for a new main control board (part # D/CB01‑00187).

Step‑by‑Step Fix for the Most Common Cause

(Faulty Door Latch Switch – 70 % of SYMPTOM‑WONT‑START cases)

Safety First

Unplug the dryer from the wall outlet or shut off the dedicated 240 V breaker.
Wear insulated gloves; keep a fire‑rated vacuum nearby to clear any lint that may have accumulated near the door seal.

Tools Required

Phillips #2 screwdriver
T20 Torx driver (for control panel screws)
Flat‑head screwdriver (to pry the latch cover)
Digital multimeter (continuity mode)
Needle‑nose pliers (for spring removal)
Vacuum with hose attachment (optional, for cleaning)

Procedure

Step	Action	Details
1	Remove the front panel	Unscrew the two Phillips screws at the top of the dryer’s front edge. Slide the panel down and lift it off.
2	Locate the door latch assembly	It sits just behind the door gasket, attached to the frame with two 6 mm screws. The latch includes a small plastic lever and a metal switch.
3	Test the latch switch	With the dryer still unplugged, disconnect the two wires from the latch. Set the multimeter to continuity. Press the latch lever; the meter should beep. No beep = bad switch.
4	Inspect the mechanical parts	Look for broken springs, cracked plastic, or lint jammed in the latch groove. Clean any debris with the vacuum.
5	Replace the latch (if needed)	- Remove the two mounting screws. - Pull the old latch out, noting the wire orientation. - Insert the new latch, align the wires, and tighten the screws.
6	Re‑assemble the dryer	Snap the front panel back into place, reinstall the top screws, and ensure the door gasket sits evenly.
7	Power up and test	Plug the dryer back in, close the door firmly, and press Start. The drum should spin and the error code should disappear.
8	Confirm “fixed”	Run a 5‑minute timed cycle. If the dryer completes the cycle without flashing SYMPTOM‑WONT‑START, the repair succeeded. If the code returns, move on to the next root cause.

What “fixed” looks like: The dryer starts on the first press, the drum rotates smoothly, and the display shows the ready light. No error codes appear during the cycle.

What “still broken” looks like: The dryer remains silent, the error code reappears within seconds, or the drum spins but the dryer still reports a start fault. In those cases, verify the latch wiring and proceed to the start‑switch diagnosis.

Model‑Specific Differences

Samsung’s dryer lineup (2015‑2023) shares the same diagnostic logic, but a few nuances affect how SYMPTOM‑WONT‑START manifests:

Model Series	Years	Notable quirks	Firmware/Recall notes
DV45K6500EV	2015‑2018	Door latch switch mounted on a plastic bracket that can crack under repeated slamming.	Firmware v1.04 (released 2017) added a “door‑open” debounce timer; updating via Samsung SmartThings can resolve intermittent codes.
DV80M9900EV	2019‑2021	Uses a dual‑sensor door latch (mechanical + magnetic Hall sensor). Both must be functional.	No recall, but Samsung released a service bulletin (SB‑2020‑09) recommending inspection of the Hall sensor coil.
DV90T8240EW	2022‑2023	Integrated control board with a separate “start‑signal” IC. A blown IC can mimic a latch failure.	Early 2023 units had a known issue where moisture ingress from the vent caused the start‑signal IC to short. Samsung offers a free board replacement for units under 2 years.

How to check firmware version:

Press and hold Temp and Time simultaneously for 3 seconds. The display will scroll the firmware code (e.g., V1.04).
If the version is older than the latest listed on Samsung’s support site, connect the dryer to Wi‑Fi and use the SmartThings app to push the update.

Recall tip: If your dryer’s serial number falls within the 2022‑03 batch for the DV90T8240EW, call Samsung support at 1‑800‑726‑7864 and ask for the “start‑signal IC” replacement program.

What You’ll Pay to Fix This

Repair Option	DIY Parts Cost*	DIY Labor (time)	Professional Labor (hourly)	Typical Pro Quote
Door latch switch	$30–$45	45 min	$80–$120	$120–$165 (parts + labor)
Start switch	$25–$40	60 min	$80–$120	$130–$180
Thermal fuse	$12–$18	20 min	$80–$120	$100–$138
Drive belt	$20–$35	70 min	$80–$120	$150–$185
Motor capacitor	$15–$30	45 min	$80–$120	$115–$150
Control board	$120–$180	90 min (if you’re comfortable)	$80–$120	$260–$340 (parts + labor)

*Prices are based on Samsung OEM parts purchased from authorized distributors (as of May 2026). Taxes and shipping are not included.

When to replace vs. replace the whole dryer:

If the dryer is older than 12 years and multiple components have failed, the cumulative cost can exceed $400, making replacement a more economical choice.
Units still under Samsung’s 1‑year limited warranty (or a 10‑year motor warranty) can have parts shipped free; just provide the serial number when you call 1‑800‑726‑7864.

Keeping This Error Away Long-Term

Clean the door gasket weekly – Use a soft cloth and mild detergent. A dirty gasket can prevent the latch from fully engaging, leading to false “door open” signals.
Vacuum the lint trap and vent every 2 weeks – Excess lint raises the internal temperature, increasing the chance of a thermal‑fuse blowout.
Avoid overloading – A drum packed beyond ¾ capacity stresses the belt and motor, which can cause a start‑signal failure.
Inspect the start button for wear – If the button feels mushy, replace the start switch before it fails completely.
Schedule a semi‑annual service – Have a qualified technician check the door latch spring tension, test the thermal fuse, and verify the control board firmware.

Following these habits reduces the odds of encountering SYMPTOM‑WONT‑START by more than 80 % in typical household use.
