LG Dryer tE1 Error — How to Fix (Thermistor Short Circuit)

The LG Dryer error tE1 can be frustrating, especially when you have a load of laundry to finish. This error code indicates a problem with the temperature sensor, also known as the thermistor. When the thermistor is faulty or shorted, the dryer thinks it’s overheating and shuts off the heating element to protect the drum. As a result, your dryer won’t heat or dry clothes properly.

What LG Dryer Error tE1 Actually Means

The tE1 error code on your LG Dryer signifies a short circuit in the temperature sensor or thermistor. This sensor is crucial for monitoring the dryer’s temperature and ensuring it operates within safe limits. When the thermistor is shorted, it sends incorrect readings to the dryer’s control board, causing the dryer to malfunction. The error code essentially acts as a protective measure to prevent overheating and potential fires.

The thermistor is usually located near the heating element or on the blower wheel housing. It’s a small, cylindrical part attached to the harness with wires. When the thermistor fails or becomes shorted, it disrupts the dryer’s ability to regulate temperature, leading to the tE1 error.

Rapid Diagnosis Guide

Before calling a professional, try these quick diagnostic steps:

• Power Cycle the Dryer: Unplug the dryer, wait 60 seconds, and then plug it back in. This simple reset might clear the error code if it was caused by a temporary glitch.
• Inspect the Exhaust Vent: Detach the vent hose and vacuum lint from the hose and the dryer’s vent outlet. A clogged vent can cause overheating, which might trigger the tE1 error.
• Check for Overloaded Dryer: Ensure you’re not overloading the dryer, as this can cause uneven drying and potentially trigger the error.

Why This Error Appears (Top Causes)

Here are the common causes of the tE1 error on LG Dryers, ranked by likelihood:

1. Faulty Thermistor (80% likelihood)

• Description: The thermistor is a temperature-sensing device that monitors the dryer’s temperature. When it fails or becomes shorted, it can trigger the tE1 error.
• How to Verify: Use a multimeter to test the thermistor’s resistance. A shorted thermistor will show very low resistance (near 0 ohms).
• Fix Difficulty: Medium
• Cost: $20-$50 (thermistor part cost)

2. Wiring Issues (15% likelihood)

• Description: Damaged or corroded wiring can cause a short circuit, leading to the tE1 error.
• How to Verify: Inspect the wiring harness and connections for signs of damage or corrosion.
• Fix Difficulty: High
• Cost: $50-$200 (wiring repair or replacement)

3. Control Board Issues (5% likelihood)

• Description: In rare cases, a faulty control board can cause the tE1 error.
• How to Verify: Check the control board for signs of damage or burn marks. Test the board’s inputs and outputs with a multimeter.
• Fix Difficulty: High
• Cost: $100-$300 (control board replacement)

Step -Step Fix for the Most Common Cause

The most common cause of the tE1 error is a faulty thermistor. Here’s a step-by-step guide to replace it:

Safety Precautions

• Unplug the dryer from the power outlet to prevent electrical shock.
• Wear protective gloves and safety glasses.

Tools Needed

• Phillips #2 screwdriver
• T20 Torx screwdriver
• Digital multimeter (continuity function)
• Needle-nose pliers
• Vacuum cleaner with hose attachment

Step-by-Step Instructions

1. Remove the Front Panel: Loosen the two Phillips #2 screws at the bottom and the two T20 Torx screws at the top. Gently pull the panel away from the dryer.
2. Locate the Thermistor: The thermistor is usually located near the heating element or on the blower wheel housing. It’s a small, cylindrical part attached to the harness with wires.
3. Test the Thermistor: Use a multimeter to test the thermistor’s resistance. Set the meter to resistance (Ω) and disconnect the wires. A good thermistor will show a resistance value around 10kΩ at room temperature. A shorted thermistor will show very low resistance (near 0 ohms).
4. Replace the Thermistor: Remove the retaining clip or screw, pull the old sensor out, and disconnect the wires. Install the new thermistor, connect the wires, and secure it with the retaining clip or screw.
5. Reassemble the Dryer: Put the front panel back, reinstall the Phillips and Torx screws, and plug in the dryer.

What Differs Between Models

The tE1 error can occur on various LG Dryer models, but some models are more prone to this issue:

• LG Dryer Models: DLEX3900W, DLEX3900R, DLEX3900S, and others from the same series.
• Firmware Updates: Check for firmware updates on the LG website or through the LG SmartThinQ app. Some updates may address issues related to the tE1 error.

Budget Planning: Repair Costs

Here’s a breakdown of the estimated repair costs:

Proactive Maintenance Checklist

To prevent the tE1 error and ensure your LG Dryer’s longevity:

• Regularly Clean the Lint Filter: Clean the lint filter after each use to prevent lint buildup.
• Inspect and Clean the Exhaust Vent: Check and clean the exhaust vent every 6 months to ensure proper airflow.
• Don’t Overload the Dryer: Avoid overloading the dryer, as this can cause uneven drying and potentially trigger the tE1 error.

Signs You Need a Certified Technician

If you’re not comfortable with DIY repairs or if the issue persists after trying the above steps, consider calling a professional:

• Symptoms: Dryer won’t heat, dryer won’t dry clothes, or the tE1 error persists after trying the above steps.
• What to Expect: A professional technician will diagnose the issue, provide a repair estimate, and perform the necessary repairs.

Frequently Asked Questions

Here are some common questions related to the LG Dryer error tE1:

• Q: What causes the tE1 error on my LG Dryer? A: The tE1 error is usually caused by a faulty thermistor, wiring issues, or control board problems.
• Q: Can I fix the tE1 error myself? A: Yes, you can try to fix the tE1 error yourself by replacing the thermistor or checking the wiring. However, if you’re not comfortable with DIY repairs, consider calling a professional.
• Q: How much does it cost to replace the thermistor? A: The cost to replace the thermistor can range from $20 to $50, depending on the part and labor costs.
• Q: Is it worth fixing my LG Dryer or should I replace it? A: If your dryer is still under warranty or if the repair cost is less than 50% of the dryer’s original price, it’s likely worth fixing. Otherwise, consider replacing it.
• Q: Can I prevent the tE1 error from happening again? A: Yes, you can prevent the tE1 error by regularly cleaning the lint filter, inspecting and cleaning the exhaust vent, and not overloading the dryer.

For more information on LG appliance errors, visit our pages on LG Dishwasher error AE, LG Dishwasher error FE, or LG Dryer error CL.
