What Does Error Code E14 Mean?

Error E14 on your Bosch Dishwasher means: Error code E14 on your Bosch Dishwasher indicates a flow sensor error. This means the dishwasher is not detecting water flow, which prevents it from completing the wash cycle. You may see a flashing error light or an error message on the display.

What You'll Need

🔧 Tools

Multimeter
Torx T20 screwdriver
Phillips

🛒 Parts

Flow sensor

How to Fix Error E14 — Step by Step

1

Step 1: Reset the Dishwasher

First, try resetting the dishwasher by unplugging it from the power outlet and plugging it back in. This can sometimes resolve the issue. Wait for 30 seconds before turning it back on and checking if the error code is still present.
2

Step 2: Check the Water Supply

Next, check the water supply lines to ensure they're not kinked or blocked. Make sure the water valves are fully open. Check the water pressure by attaching a pressure gauge to the supply line. The ideal pressure range is between 20-80 PSI.
3

Step 3: Inspect the Flow Sensor

Locate the flow sensor, usually located near the water inlet valve. Use a Torx T20 screwdriver to remove the screw holding the sensor in place. Gently pull the sensor out and inspect it for any signs of blockage or damage.
4

Step 4: Check the Water Inlet Valve

Next, inspect the water inlet valve for any signs of blockage or mineral buildup. Use a Phillips #2 screwdriver to remove the screws holding the valve in place. Gently pull the valve out and inspect it for any signs of damage or blockage.
5

Step 5: Replace the Flow Sensor (if necessary)

If the flow sensor is damaged or clogged, you may need to replace it. Purchase a replacement flow sensor from the manufacturer or a reputable supplier. Follow the manufacturer's instructions for installation. The cost of a replacement flow sensor can range from $50 to $150, depending on the model and supplier.
6

Step 6: Reassemble and Test

Once the flow sensor is replaced, reassemble the dishwasher in the reverse order of how you disassembled it. Turn on the dishwasher and check if the error code is still present. Run a test cycle to ensure the dishwasher is working properly.

When to Call a Professional

Should you feel uncertain about the repair process, or if the error code persists after trying the above steps, this is a good time to call in professional help.

If you’re seeing the E14 error code on your Bosch dishwasher, it can be frustrating and worrisome. This error indicates a flow sensor issue, which prevents the dishwasher from detecting water flow and completing the wash cycle. Don’t worry; we’ll walk you through what this error means, how to diagnose it, and steps to fix it.

What Bosch Dishwasher Error E14 Actually Means

The E14 error code on your Bosch dishwasher is related to the flow sensor. The flow sensor is responsible for measuring the water flow into the dishwasher. When the dishwasher detects a problem with the water flow, it displays the E14 error code. This error can occur due to a faulty flow sensor, clogged water inlet valve, or issues with the water supply.

The flow sensor is usually located near the water inlet valve and is responsible for monitoring the water flow into the dishwasher. If the sensor detects a problem, it sends a signal to the control board, which displays the E14 error code.

Is it safe to keep using the appliance? No, it’s not recommended to continue using the dishwasher with the E14 error code. The dishwasher may not be able to complete the wash cycle, and continued use can lead to poor cleaning performance, increased energy consumption, and potentially cause further damage to the appliance.

Quick Diagnostic Checklist (use before calling anyone)

Before calling a professional or spending money on repairs, try these quick diagnostic checks:

Check the water supply: Ensure the water supply lines are not kinked, clogged, or restricted.
Check the water inlet filter: Locate the water inlet filter and clean or replace it if necessary.
Power cycle the dishwasher: Unplug the dishwasher from the power outlet, wait for 30 seconds, and plug it back in. This can sometimes reset the error code.

For Bosch dishwashers, the power cycle procedure is as follows:

Unplug the dishwasher from the power outlet.
Wait for 30 seconds to allow any residual power to dissipate.
Plug the dishwasher back in and turn it on.

Model-Specific Notes

Different Bosch dishwasher models may have variations in the flow sensor and water inlet valve location. Make sure to consult your dishwasher’s user manual or online documentation for specific instructions on locating and replacing these parts.

Bosch 800 Series (SHU, SHV, STH): The flow sensor is located near the water inlet valve on the bottom right side of the dishwasher.
Bosch 600 Series (SHU, SHV, STH): The flow sensor is located near the water inlet valve on the bottom left side of the dishwasher.
Bosch 400 Series (SHU, SHV, STH): The flow sensor is located near the water inlet valve on the bottom center of the dishwasher.

Root Causes (Ranked by Likelihood)

Here are the common causes of the E14 error code on Bosch dishwashers, ranked by likelihood:

1. Faulty Flow Sensor

Description: The flow sensor is damaged or faulty, preventing it from accurately measuring water flow.
How to verify: Check the flow sensor for any signs of damage or corrosion. Use a multimeter to test the sensor’s resistance.
Fix difficulty: Medium
Cost: $50-$150 (part number: 00653066)

2. Clogged Water Inlet Valve

Description: The water inlet valve is clogged or restricted, preventing water from flowing into the dishwasher.
How to verify: Check the water inlet valve for any signs of blockage or corrosion. Clean or replace the valve if necessary.
Fix difficulty: Medium
Cost: $20-$50 (part number: 00422635)

3. Water Supply Issues

Description: Issues with the water supply lines, such as kinking or clogging, prevent water from flowing into the dishwasher.
How to verify: Check the water supply lines for any signs of kinking or clogging. Clean or replace the supply lines if necessary.
Fix difficulty: Easy
Cost: $10-$30 (depending on the replacement supply line)

4. Blockages in the Drain Pump Filter

Description: Blockages in the drain pump filter can prevent water from flowing into the dishwasher.
How to verify: Check the drain pump filter for any blockages. Clean or replace the filter if necessary.
Fix difficulty: Easy
Cost: $10-$30 (depending on the replacement filter)

5. Faulty Water Inlet Valve Solenoid

Description: The water inlet valve solenoid is faulty, preventing the valve from opening.
How to verify: Use a multimeter to test the solenoid’s resistance.
Fix difficulty: Medium
Cost: $20-$50 (part number: 00422636)

What to Check Before Calling a Professional

Before calling a professional, make sure to check the following:

Error code display: Ensure the E14 error code is displayed on the dishwasher’s display panel.
Flow sensor location: Locate the flow sensor and check for any signs of damage or corrosion.
Water supply lines: Check the water supply lines for any signs of kinking or clogging.

Firmware Updates

Bosch dishwashers may require firmware updates to resolve issues with the flow sensor. Check your dishwasher’s user manual or online documentation for instructions on updating the firmware.

Bosch Home Connect App: Download the Bosch Home Connect app to update your dishwasher’s firmware remotely.
Online Support: Visit Bosch’s website to download and install firmware updates.

Common Misdiagnoses

Don’t make the following common mistakes when diagnosing the E14 error code:

Assuming the flow sensor is faulty: Check the water supply lines and inlet valve before assuming the flow sensor is faulty.
Ignoring the water supply lines: Check the water supply lines for any signs of kinking or clogging before assuming the flow sensor is faulty.
Not cleaning the drain pump filter: Clean the drain pump filter regularly to prevent blockages.

Conclusion

The E14 error code on your Bosch dishwasher is related to the flow sensor. To fix this issue, try the quick diagnostic checks and steps outlined in this article. If the error code persists, consider consulting a professional for further assistance.

Remember to always follow the manufacturer’s instructions for repair and maintenance to ensure your dishwasher operates safely and efficiently.

Time Estimate: 30-60 minutes

Tools Needed:

Multimeter
Torx T20 screwdriver
Phillips
Water pressure gauge
Drain pump filter cleaning tool (optional)

Cost Estimate: $10-$150 (depending on the replacement parts and tools needed)
